Specialise in manufacturing ZJ15-ZJ70 Drilling Rig:
Mechanical Drilling Rig;
Truck-Mounted Drilling Rig;
Digital Control Frequency Conversion Rig.
The main characteristic of drilling rig:
1. Modularize design,block package structure,connected with pins between sections.
2. Connected with cardan shaft, easy to install,dismount and deliver.
3. Front opening mast, installed at low position, integrally lifting.
4. Aulixilary driving equipments which are used to lift the mast and deal with emergency cases.
5. Integral chain driving box.
Electric Drive Rig
|
Model |
ZJ30/
1700DB |
ZJ40/
2250DB |
ZJ50/
3150D |
ZJ50/
3150DB |
ZJ70/
4500D |
ZJ70/
4500DB |
|
Nominal drilling depth
(114mmdrilling pipe) |
1600~3000 |
2500~4000 |
3800~5000 |
3800~5000 |
4500~7000 |
4500~7000 |
|
Max. Hook Load |
1700 |
2250 |
3150 |
3150 |
3150 |
4500 |
|
Number of Lines of Hoisting System |
10 |
10 |
12 |
12 |
12 |
12 |
|
Dia.of Wireline for Hoisting |
29(11/8) |
32(11/4) |
35£¨13/8£© |
35£¨13/8£© |
38£¨11/2) |
38£¨11/2) |
|
Max. Pull of Fast Line |
210 |
280 |
350 |
350 |
485 |
485 |
|
Drawworks |
Model |
JC30DB |
JC40DB |
JC50D |
JC50DB |
JC70D |
JC70DB |
|
Rated Power of
Drawworks |
550 |
735 |
1100 |
1100 |
1470 |
1470 |
|
Speed |
I, Smooth Change |
I, Smooth Change |
4, Smooth Change |
I, Smooth Change |
4, Smooth Change |
I, Smooth Change |
|
Main Brake |
Hydraulic Disc Brake |
|
Auxiliary Brake |
Eddy Brake or EATON Brake |
|
Crown Block |
TC170 |
TC225 |
TC315 |
TC315 |
TC450 |
TC450 |
|
Traveling Block |
YC225 |
YC225 |
YC315 |
YC315 |
YC450 |
YC450 |
|
Hook |
DG225 |
DG225 |
DG315 |
DG315 |
DG450 |
DG450 |
|
Swivel |
Model |
SL225-II |
SL225-II |
SL450-II |
|
ID of Swivel Stem |
75 |
|
Rotay Table |
Model |
ZP520 orZP275 |
ZP375 |
|
Dia.of Opening |
520.7(201/2) or 698.5(271/2) |
952.5(371/2) |
|
Speed |
II ,smooth change |
II ,smooth change |
II, smooth change |
1,smooth change |
II, smooth change |
1, smooth change |
|
Mud Pump |
Model¡ÁNumber |
F-1300¡Á2 |
F-1300¡Á2 |
F-1600¡Á2 |
F-1600¡Á2 |
F-1600¡Á3 |
F-1600¡Á3 |
|
Power of Each
Mud Pump |
960(1300) |
960(1300) |
1180(1600) |
1180(1600) |
1180(1600) |
1180(1600) |
|
Drive Mode |
Electric drive |
|
Mast |
Type |
K |
|
Working Height |
41.5 |
41.5 |
43 |
43 |
45 |
45 |
|
Height of Drilling Floor |
7.5 |
7.5 |
9 |
9 |
9 |
9 |
|
Clear Height of Drilling Floor |
6.26 |
6.26 |
7.7 |
7.7 |
7.7 |
7.7 |
Mechanical Drilling Rig
|
Model |
ZJ130/1700L |
ZJ40/2250L(LDB) |
ZJ50/3150L(LDB) |
ZJ70/4500L(LDB) |
|
m
Nominal Drilling Depth
(114mm Drilling Pipe) |
1600~3000 |
2500~4000 |
3500~5000 |
4500~7000 |
|
Max hook load |
1700 |
2250 |
3150 |
4500 |
|
Number of Lines of
Hoisting System |
10 |
10 |
12 |
12 |
|
Dia.of Wire Line |
29(11/8) |
32(11/4) |
35(13/8) |
38(11/2) |
|
Max. Pull of Fast Line |
210 |
280 |
340 |
485 |
|
Model of Drawworks |
JC30L |
JC40L |
JC40LDB |
JC50L |
JC50LDB |
JC70L |
JC70LDB |
|
Rated Power of Drawworks |
550 |
735 |
1100 |
1470 |
|
Speed of Drawworks |
4Forward+
2Reverse |
4Forward+
2Reverse |
4Forward |
4Forward+
2Reverse |
4Forward |
6Forward+
2Reverse |
6Forward |
|
Main Brake of Drawworks |
Hydraulic Disc Brake |
|
Auxiliary Brake of Drawworks |
Eddy Brake |
Eddy Brake or EATON Brake |
|
Crown Block |
TC170 |
TC225 |
TC315 |
TC450 |
|
Traveling Block |
YC225 |
YC225 |
YC315 |
YC450 |
|
Hook |
DG225 |
DG225 |
DG315 |
DG450 |
|
Model of Swivel |
SL225-II |
SL225-II |
SL225-II |
SL450-II |
|
mm
lD of Swivel Stem |
75 |
|
Model of Rotary Table |
ZP520 or
ZP275 |
ZP520 orZP275 |
ZP375 |
ZP375 |
|
Dia. of Opening of Rotary Table |
520.7(201/2)
or
698.5(271/2) |
520.7(201/2)or
698.5(271/2) |
952.5(371/2) |
952.5(371/2) |
|
Speed of Rotary Table |
4Forward+
2Reverse |
4Forward+
2Reverse |
2 Reverse |
4Forward+
2Reverse |
2 Reverse |
6Forward+
2Reverse |
2µµ Reverse |
|
Model¡ÁNumber of Mud Pump |
F-1300¡Á1 |
F-1300¡Á2 |
F-1600¡Á2 |
F-1600¡Á2 |
|
Power of Each Mud Pump |
960(1300) |
960(1300) |
1180(1600) |
1180(1600) |
|
Drive Mode of Mud Pump |
Compound drive |
|
Type of Mast |
K |
|
Working Height of Mast |
41.5 |
43 |
45 |
45 |
|
Height of Drilling Floor |
4.5 or 6 |
6 or 7.5 |
7.5 or 9 |
9 |
|
Clear Height of Drilling Floor |
3.44 or
4.67 |
4.67 or 6.26 |
6.26 or 7.7 |
7.7 |
|
